621-2101 – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
Output Module 115VAC.
Model No : 621-2101R.
Output Rating : 90-140 VAC, 2A per Circuit.
Special Feature : Isolated Output.
Nominal Voltage : 115 Vac.
Voltage Range : 90-140 Vac.
Maximum Current Range : 2 A/circuit.
Surge Current : 15 A, 2 cycle (nonrepetitive).
Off-State Leakage Current : <=5 mA (typical).
On-State Voltage Drop : <=2 Vac at 2 A.
Fusing : 1 per circuit, 3 A slo-blo.
Operating Current +5 Vdc : 80 mA plus 24 mA for each energized output, 224 mA max.
Addressing : Lower 6 addresses.
Terminal Block Required : 621-9949.
The 'R' suffix indicates the module can be removed or inserted into an I/O rack while the rack remains powered. Other I/O modules in the rack continue to control the machine or process.
