2MLF-AC8A – Honeywell
Analog Input Modules from Honeywell
Product Specifications
Model/Part Number: 2MLF-AC8A
Industrial Usage: Programmable Logic Controller (PLC)
Part Type: Analog Input Modules
Brand/Manufacturer: Honeywell
Origin: Korea
Delivery: AS per Standard
Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.
In-Stock: 1
Available, can ship immediately
Part Details:
Honeywell make Master logic 200 series assemblies- 2MLF-AC8A Analog Input Module
- Product No. : 2MLF-AC8A.
- Product type : Analog Input Modules 8 channel Current Input.
- Module Accuracy : ±0.2% or less (when ambient temperature is 25 (±5) o C) ±0.3% or less (when ambient temperature is 0 ~ 55 o C).
- Max. conversion speed : 250 µs/channel.
- Absolute max. input : ±30.
- Analog input channels : 8 channels/1 module.
- Isolation method : Photo-coupler isolation between input terminal and PLC power (no isolation between channels).
- Terminal connected : 18-point terminal.
- I/O addresses assigned : Fixed type: 64 points, Variable type: 16 points.
- Current Consumption : DC 5 V: 420 mA.
