2MLI-D24A – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
2MLI-D42A - 32Point DC 24V Input Module (Source/Sink type).
Brand :Honeywell.
Input Point : 32point.
Isolation method : Photo Coupler Isolation.
Rated Input Voltage : DC 24V.
Rated input current : About 4mA.
Operation voltage range : DC 20.4 ~ 28.8V(ripple rate>5%).
Input Derating : yes.
On Voltage / Current : DC19V or higher /3mA or higher.
Off Voltage / Current : DC11V or lower / 1.7mA or higher.
Input resistance : About 5.6kΩ.
Isolation Voltage : AC 560Vrms/3 Cycle.
Isolation resistance : 10mΩ. or more by mega.
Common method : 32point /com.
Proper Cable Size : 0.3mm.
Current Consumption(mA) : 50mA.
