2MLR-AC22 – Honeywell
MasterLogic-200 from Honeywell
Product Specifications
Model/Part Number: 2MLR-AC22
Industrial Usage: Programmable Logic Controller (PLC), Control and Instrumentation Spares
Warranty: One year
Part Type: MasterLogic-200
Brand/Manufacturer: Honeywell
Origin: Korea
Delivery: 1 Week
Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.
In-Stock: 1
Available, can ship immediately
Part Details:
Power Module, 5.5A, Voltage (AC220V)
- Model No : 2MLR-AC22.
- Rated input voltage : 220VAC.
- Input voltage range : 176V~264VAC.
- Input frequency : 50 / 60 Hz (47 ~ 63 Hz).
- Efficiency : 65% or higher.
- Inrush current : 20A peak and lower (within 8 ).
- Input fuse : Built in(not replaceable by a user).
- - AC power : 250V / 3.15A ( Time-lag Type ) UL approved.
- - DC power : 125V/10A (Time-lag type).
- UL approved Allowed instantaneous interruption : Within 20.
- Output voltage : 5VDC (±2%).
- Rated switching voltage/current : 24VDC, 0.5AMin.
- switching load : 5VDC,
- 1Response time : Off → On/ On → Off : 10 and lower/12 and lower Voltage status display: LED On when output voltage is normal.
- Specification of cable : 0.75 ~ 2 mm(Power 2).
- Max. input power : 110 VA / 42 W.
- Over current protection : 6.0 A ~ 13.0 A / 9.3 A ~ 17.0 A.
Packaging Details:
As per International Standard.
