621-6500R – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
12-24 Vdc source output Module.
Outputs : 8.
Points Per Common : 4.
Special Feature : Source Output.
Nominal Voltage : 12-24 Vdc.
Voltage Range : 11-32 Vdc.
Maximum Current Range : 2 A/circuit, 6 A/common, 8A/module.
Surge Current : 8 A for 10ms (nonrepetitive).
Field Power Requirement : 15 mA at 12 Vdc , 32 mA at 24Vdc for each energized output.
Off-State Leakage Current : <=5 mA (typical).
On-State Voltage Drop : <=2 Vdc at 2 A.
Fusing : 8 A fast blow per group of 4.
Operating Current +5 Vdc : 70 mA plus 5 mA for each energized output, 110 mA max.
Terminal Block Required : 621-9949.
The 'R' suffix indicates the module can be removed or inserted into an I/O rack while the rack remains powered. Other I/O modules in the rack continue to control the machine or process.
