AAB841 – Yokogawa
Analog Input/ Output Module from Yokogawa
In-Stock: 1
Available, can ship immediately
Part Details:
- YOKOGAWA make AAB841 Analog Input / Output Module.
- Number of input channels : 8-channel input/8-channel output.
- non-isolated (differential input).
- I/O Signal:
- Input : 1 to 5 V (allowable common mode voltage ±1 V or less).
- Output : 4-20MA.
- Allowable input current / voltage : ±7.5 V.
- Input resistance : Power on- 1 MΩ or larger , Power Off- 340kΩ or larger.
- Accuracy : Input: ±4 mV, output: ±48 μA.
- Maximum current.
- consumption : 310 mA (5 V DC), 250 mA (24 V DC).
