CN7505A2001 – Honeywell

Part Details:

5Nm, 24Vac/Vdc, Modulating control, Non-Spring return, Voltage Feedback Signal and without aux. Switch.

Model No : CN7505A2001.

Modulating control : 50036196-001.

Torque rating : 44 lb-in. (5Nm).

Control signal :  Modulating (0)2...10 Vdc.

Floating/2-Position 24 Vac/dc.

Supply voltage : 24 Vac/dc -15%/+20%, 50/60 Hz.

End switches (when included) :

Rating : Class II.

Triggering points : 5° / 85°.

Power consumption : 5 VA / 2 W.

Rotation stroke : 95° C.

Protection standard : IP54.

Built in rotation limiter : yes.

Manual operation : yes.

Runtime : 95s.
