FBM242 – Foxboro

Part Details:

Foxboro ( by Schneider Electric ) Make FBM242 Externally Sourced, Discrete Output Interface

Module Product No. :  FBM242

Product Type : Externally Sourced, Discrete Output Interface ModuleFeatures : Sixteen discrete outputs, Supports discrete output signals at voltages of 15 to 60 V dc ,120 V ac/125 V dc , 240 V ac , Each input and output is galvanically isolated , group isolated when used with external excitation , Compact, rugged design suitable for enclosure in Class G3 (harsh) environments, Executes the Discrete I/O or Ladder Logic program, with the following configurable options Input Filter Time, Fail Safe Configuration, Fail , Safe Fall-Back, and Sustained or Momentary Outputs

Input Voltage Range (Redundant) : 24 V dc +5%, -10%

Consumption (Maximum) : 3 W (maximum) at 24 V dc

Heat Dissipation : 6.5 W (maximum) at 24 V dc (with all outputs at 1.5 A each)

Calibration Requirements : The module and termination assemblies require no calibration.

Temperature Module : -20 to +70°C (-4 to +158°F)

Termination Assembly PVC : -20 to +50°C (-4 to +122°F)

Relative Humidity : 5 to 95% (noncondensing)

Dimensions (L x W x H) : 10.4 cm x 4.5 cm x 11.4 cm

Weight : 0.284 kg
