HCU16 – MTL

HART CONNECTION UNIT from MTL

Product Specifications

Model/Part Number: HCU16

Part Type: HART CONNECTION UNIT

Brand/Manufacturer: MTL

Delivery: AS per Standard

Datasheet:

Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.

In-Stock: 1

Available, can ship immediately

Part Condition

Choose Part Conditions

Part Availability

Choose Part Availability

Part Details:

MTL - HCU16 - MTL4840 Series HART® Connection Unit - 16 Channel - Analogue Input

  • Power requirements, Vs: 21 to 35V dc through plug-in connectors
  • Interface bus connector: 10-way ribbon socket
  • RS485 port: 2.5mm2 screw terminals
  • Accuracy (HCU16-P250 only): 250Ω ±0.05%
  • Connectors:
    • 2.5mm2 screw clamp terminals
    • 3 terminals per channel
    • 20-way flat cable (to BPHM64)
  • Weight: 383g
  • Capacity: 16 channels
  • Isolation: Channel to channel 50V dc
  • Mounting: Supplied fitted with DIN-rail (T- or G- section) carrier
