IC693ALG392-BE – GE Fanuc
Output Analog Current from GE Fanuc
In-Stock: 1
Available, can ship immediately
Part Details:
IC693ALG392 is an Analog Current/Voltage Output Module for the PAC Systems RX3i and Series 90-30.
NO. of channel : 8.
Voltage output range : 0 to +10v (unipolar) or -10 to +10v (bipolar).
Current output range : 0 to 20m A to 4 to 20m A.
Update rate : 8m sec (all channel).
Max output load : 5mA.
Power consumption : 110mA from +5v bus or 315 mA from +24v uses supply.
