IC693PWR321Y – GE Fanuc
Power supply from GE Fanuc
In-Stock: 1
Available, can ship immediately
Part Details:
Technical Specifications
Manufacture : GE Fanuc.
Model / Part No. : IC693PWR321Y.
Load Capacity : 85 to 264 VAC or 100 to 300 VDC.
Input Power : 90 VA with VAC or 50 W with VDC.
Load Capacity : 30 Watts.
Nominal Rated Voltage : 120/240 VAC or 125 VDC.
Location on Baseplates : Leftmost Slot.
Communication : RS 485 Serial Port.
- Input Voltage:
– Nominal Voltage : 120/240 VAC.
– Voltage Range : 85-264 VAC.
– Frequency : 47-63 Hz.
– Inrush Current : <20 A @ 120 VAC, <40 A @ 240 VAC.
- Output Voltage:
– Nominal Voltage : 24 VDC.
– Voltage Range : 20-28 VDC.
– Rated Current : 5.0 A.
– Peak Current : 12 A for 10 ms.
