M24-20HE – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
24 Vdc power supply (20 A).
Model No : M24-20HE.
Power requirements : 110 or 117 Vac (10 AT fuse), ± 10"0, 230 or 240 Vac (6.3 AT fuse),± 10%.
Frequency : 50 / 60 Hz (48...62 Hz).
Ambient temperature : –20°C to +60°C (–4°F to +140°F).
Input current : 3.7 A at 220 Vac.
Inrush current : < 80 A at 220 Vac.
Output voltage : 24 Vdc with overvoltage protection.
Ripple content : < 0.1 V p-p.
Output current : 20 A at –20°C to +50°C,13.5 A at 50°C to 60°C.
Hold-up time : nominal AC input voltage, 20 ms at full load, 50 ms at half load.
Output voltage setting : 25 Vdc(R+ output).
Maximum current setting : 21 A.
Overvoltage protection : 26 Vdc .
Efficiency :-
74%input to case : 2500 Vac DC output to case :- 500 Vdc.
The power supply M24-20HE is a linear power supply with high efficiency (74%). It is available in a number of versions that accept different AC input voltages: 110, 117, 220, 230 or 240 Vac.The power supply has an extra output (via a diode) for use irredundant operation. It also has a built-in overvoltage protection and a delayed foldback characteristic to prevent overheating in case of overload.
