MS4709F1014 – Honeywell

Part Details:

TWO POSITION DIRECT COUPLED ACTUATOR.

Model No : MS4709F1014.

80 lb-in Fast-Acting, Two-Position Actuator.

Minimum Driving Torque at 350 F (lb-in.) :  80 lb-in.

Timing, Maximum Driving @ 60 Hz (sec) :  25 sec.

Actuator Type : Damper.

Application Type : Fire and Smoke.

Torque/Force (lb-in., lbf) :  80 lb-in.

Torque/Force (Nm, N) : 9 Nm.

Minimum Driving Torque at 175 C (Nm) : 9 Nm.

Electrical Connection Length (in.) : 39 in.

Minimum Driving Torque at 350 F (Nm) : 9 Nm.

Electrical Connection Length (m) : 1 m.

Supply Voltage : 230 Vac ±10%.

Fail Safe Mode : Spring Return.

Number of Internal Auxiliary Switch : 0.

Control Signal : Two position.
