PXF4ACY2-1VYOT – Fuji Electric
Universal input: thermocouple, RTD, voltage, current, mV from Fuji Electric
Product Specifications
Model/Part Number: PXF4ACY2-1VYOT
Warranty: One year
Part Type: Universal input: thermocouple, RTD, voltage, current, mV
Brand/Manufacturer: Fuji Electric
Delivery: 1 week
Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.
In-Stock: 1
Available, can ship immediately
Part Details:
- Input type : Universal
- input : thermocouple, RTD, voltage, current, mV.
- Sampling rate : 50 ms.
- Accuracy : Thermocouple
- input : either ±1°C ±1 digit or ±0.3% of indicated value ±1 digit, whichever is larger.
- RTD input : ±0.2% of indication value ±1 digit or ±0.8°C ± 1 digit, whichever is larger.
- Voltage and current input : ±0.3% FS ± 1digit.
- Control cycle : 0.1 s to 99 s.
- Output type : Relay contact output, SSR/SSC drive output, current output, voltage output, motor-operated valve control output.
- Control : ON/OFF, PID, PID2, fuzzy, 2-degrees-of-freedom PID, auto tuning, self tuning.
- Communication : Communication port x 1 (for optional USB cable) RS-485 port x 1 (Modbus RTU protocol).
- Other functions : Ramp soak (simple program control) : up to 64 steps.
- SV/PID selection : up to 8 groups.
- Soft start:
- User-defined keys.
- Auto/manual switching.
- Simple watt-hour monitoring.
- Operating days alarm.
- Heating/cooling control (option).
- Alarm (option).
- Multidrop control via RS-485 network, parameter copy, program less communication.
- Contact output (option) : 0.1 s to 99 s.
- Output type : Relay contact output, SSR/SSC drive output, current output, voltage output, motor-operated valve control output.
- Contact output (option) : up to 5 (PXF4: up to 3).
- Contact input (option) : up to 3 (PXF4: up to 1).
- Transfer output (option) : Output signal: voltage or current.
- Remote SV input (option) : Input signal: voltage or current.
- Display : M. V. A. LCD, 4-color, white PV display.
