Two Channel Fire And Smoke Detector Interface from MTL
Product Specifications
Model/Part Number: MTL 4061
Warranty: One year
Part Type: Two Channel Fire And Smoke Detector Interface
Origin: Made in England
Delivery: 1 week
Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.
In-Stock: 1
Available, can ship immediately
Part Details:
Two Channel Fire and Smoke Detector InterfaceModel No : MTL 4061.Origin : England.Number of channels : Two, fully floating, loop poweredInput voltage : 6 to 35VDCCurrent range : 1 to 40mA, nominalMinimum output voltage Vout at 20°C :Vin – (0.38 x current in mA) – 2V21V – (0.35 x current in mA)Maximum output voltage : 28V from 300ΩTransfer accuracy at 20°C :- Better than 400μATemperature drift : <10μA/°C (–20 to 60°C)Response time to step input : Settles to within 500μA of final value within 30msPower dissipation within unit : 0.7W maximum at 24V with 40mA signal (each channel)1.2W maximum at 35V with 40mA signal (each channel)Isolation : 250Vac between safe- and hazardous-area circuits.Safety description for each channel : 28V, 300Ω, 93mA.
