2MLR-DC42 – Honeywell

Part Details:

2MLR-DC42 power supply modules specifications to choose from, according to the site requirements e.g. flexible voltage input range, DC input power, output voltages and current rating, etc. listed below:

Input

• Rated input voltage: 24 VDC
• Input voltage range: 19.2 ~ 28.8 VDC
• Inrush current: 80A peak and lower
• Efficiency: 65% or higher
• Input fuse: Built in(not replaceable by a user)
  • AC power: 250V / 3.15A ( Time-lag Type ) UL approved
  • DC power: 125V/10A (Time-lag type) UL approved
• Allowed instantaneous interruption: Within 20 ms

Output

• Output voltage: 5VDC (±2%)
• Output current: 5.5A 8.5A 7.5A
• Output power: 37.5W @ 55℃
• Over current protection: 9.0 A~17.0 A

Relay Output

• Purpose: RUN contact
• Rated switching voltage/current: 24VDC, 0.5A
• Min. switching load: 5VDC, 1 mA
• Response time: Off→On/ On→Off: 10 ms and lower/12 ms and lower
• Life:
  • Mechanical life: 20 million and more times
  • Electrical life: rated switching current: 100 thousand and more times

Other

• Voltage status display: LED On when output voltage is normal
• Specification of cable: 0.75 ~ 2 mm²
• Available clamped terminal: RAV 1.25-3.5, RAV 2-3.5
• Dimension (W x H x D mm): 55 x 95 x 110
• Weight: 417g
• Applied base and install position: Power part of basic/extension base

Battery Specifications

• Nominal voltage/current: DC 3.0V / 1,800mAh
• Warranty period: 5 years (at ambient temperature)
• Purpose: Program and data backup, RTC operation when Power-OFF
  Specification Manganese dioxide lithium battery
• Outer dimension (mm): ∅ 17.0 X 33.5mm

I/O base, I/O interface modules, cables (2MLR-CPUH)

• Product: Power module (for 2MLRCPUH/T, 2MLRCPUH/F)
• Description: Power Module, 7.5A, Voltage (DC24V)
