531X305NTBAPG1 – GE - General Electric

Part Details:

PC Board Assembly.

Model : 531X305NTBAPG1.

Series : Mark V.

Developed by General Electric as a NTB/3TB terminal board. This card was originally developed for the 531X series of replacement drive boards. Applications include serial and relay outputs, low level analog I/O, encoders, and power supplies. Installing the NTB/3TB terminal board provides both regulated and unregulated power sources. The host drive can draw from regulated supplies rated at 5 VDC and 15 VDC or from unregulated supplies rated at 24 VDC or 120 VAC.5V and 15V encoders can be adjusted with the jumpers found on the board. A combination of seven form A and form C relay outputs are also provided by the board. All integrated relays include contacts rated at 120 VAC. The card also contains four potentiometers that allow for scaling of low level analog.

Board Dimension : As per Specification.

Origin in USA.
