621-2150 – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
Honeywell Output Module.
Model no : 621-2150.
Outputs : 16 Output On at zero crossing.
Points Per Common : 16.
Nominal Voltage : 115 Vac.
Voltage Range : 90-140 Vac.
Maximum Current Range : 2A per circuit ,12A per module.
Surge Current : 15 A, 2 cycle (nonrepetitive).
Off-State Leakage Current = 5 mA (typical).
On-State Voltage Drop = 2 Vac at 2A.
Fusing : 1 per circuit, 3A slo blow.
Operating Current +5 Vdc : 145 mA plus 24 mA for each Energized output, 529 mA maximum.
Terminal Block Required : 621-9950.
