621-2150R – Honeywell
In-Stock: 1
Available, can ship immediately
Part Details:
Honeywell Output Module.
Model No : 621-2150R.
Outputs : 16 Output On at zero crossing.
Points Per Common : 16.
Nominal Voltage : 115 VAC.
Voltage Range : 90-140 VAC.
Maximum Current Range : 2 A per circuit , 12 A per module.
Surge Current : 15 A, 2 cycle (nonrepetitive).
Off-State Leakage Current = 5 mA (typical).
On-State Voltage Drop = 2 Vac at 2 A.
Fusing = 1 per circuit, 3 A slo blow.
Operating Current +5 Vdc = 145 mA plus 24 mA for each Energized output, 529 Ma maximum.
