DC1010CT-101000-E – Honeywell

Part Details:

Honeywell DC1010CT-101000-E Temperature Controller

The DC1000 family of microprocessor based controllers combine a high degree of functionality and reliability at a very low price.

Available formats: 1/16 DIN.

This controller are ideal for regulating temperature in a variety of applications, including:

• Dryers.
• Semiconductor packaging / testing.
• Plastic processing.
• Packaging machinery.
• Painting and coating.
• Climatic chambers.

The DC1000 family provides basic control requirements, plus advanced features such as motor position control, phase angle power control and Setpoint programming.

Operating conditions:

• Rated Power Supply Voltage & Frequency: AC 85 ~ 265V, 50/60Hz, DC24V (optional)
• Power Consumption: 8VA (110V), 12VA (220V)
• Ambient Temperature: -20°C ~ 65°C (-4°F ~ 149°F)
• Ambient Humidity:  50 ~ 85% RH (non condensing)

Communication:

• Type of Communication: RS-232 or RS-485. Modus rtu(HEX), Modbus ASCII
• Specification: Partity= Odd/Even, Data bit= 8bits, Stop bit=1 or 2 bit.
• Communication Speed: 2400, 4800, 9600, 19200, 38400 bps
