E5EWL-R1TC – Omron
In-Stock: 1
Available, can ship immediately
Part Details:
E5EWL-R1TC/E5EWLR1TC Omron PID/On-Off Temperature controller.
Manufacture : Omron.
Model no. : E5EWL-R1TC.
Product type : Temperature controller.
Size : 1/8DIN.
Network no. of Phase : 3Phase.
Power Supply Voltage : 100 to 240VAC.
Input Type : Thermocouple.
Alarm output : 1.
Control output : Relay output.
Operating Voltage Range : 85% to 110% of rated supply voltage.
Power consumption : 3.5VA.
Alarm output : SPST-NO,250VAC,1A.
Control method : on/off control or 2-PID Control (with auto-tuning).
Setting method : Digital Setting using front panel keys.
other function : Temperature input shift run/stop, protection function, etc.
Alarm Setting Range : 1999 to 9999(decimal point position depends on input type).
Sampling Period : 25ms.
Insulation Resistance : 20Momin (at 500VDC).
Dielectric Strength : 2300VAC, 50 OR 60 HZ for 1min (b/w terminals with different charge).
