DS200PCCAG5ACB – GE - General Electric
In-Stock: 1
Available, can ship immediately
Part Details:
Power Connect Board
Model :- DS200PCCAG5ACB.
Series :- Mark V
DS200PCCAG5ACB has 4 wire jumpers.
DS200PCCAG5ACB's jumpers are JP1, JP2, WP3, and WP4.The jumpers on DS200PCCAG5ACB select system voltage.
This board is classified as a high horsepower PCCA and should be used with high HP controllers because it has eliminated all of its snubbers and has located them somewhere else in the system.
There are 12 plug connectors on the PCCA that can be used by the PCCA to send gate pulse signals that go forward and in reverse to the SCR bridge. It also can communicate with the power supply board using another one of its plug connectors. The power supply board that should be used with this system is a DCFB-type board. This PCCA also uses Leg reactors and fuses. It uses separate or common bus transformers.
