E5CC-QX2ASM-800 – Omron

Part Details:

• Manufacturer : Omron.
• Product No. : E5CC-QX2ASM-800.
• Product Type : Temperature Controller.
• Control Output 1 : Voltage output.
• Auxiliary Output : 2.
• Communication : None.
• Heater Burnout : None.
• Event Inputs : None.
• Power Supply Voltage : 100 to 240 VAC.
• Operating Voltage Range : 85% to 110% of rated supply voltage.
• Power Consumption : 5.2 VA max. at 100 to 240 VAC, and 3.1 VA max. at 24 VAC or 1.6 W max. at 24 VDC.
• Input Impedance : Current input: 150 O max., Voltage input: 1 MO min.
• Control Method : ON/OFF control or 2-PID control (with auto-tuning).
• Number of Inputs : 2.
• Setting method : Digital setting using front panel keys.
• Indication Method : 11-segment digital display and individual indicators.
• Altitude : 2,000 m max.
