Part Details:

Phoenix Contact Interface Module.

Model :- FLKM 40.

Ambient Temperature(Operation) :- -20 °C ... 50 °C.

Ambient temperature (storage/transport)  :-  -20 °C ... 70 °C.

Max. perm. operating voltage :- < 50 V AC.

Max. perm. current (per branch) :-  1 A.

Number of positions :- 40.

Status display :-  No.

Mounting position :- any.

Degree of protection :- IP20Connection Data For Connection 1Connection name :- Field level.

Connection method :- Spring-cage connection.

Conductor cross section solid :-  0.2 mm² ... 4 mm².

Conductor cross section flexible :-  0.2 mm² ... 2.5 mm².

Conductor cross section AWG  :- 24 ...

12Connection data for connection 2.

Connection name :-  Controller level.

Connection method :- IDC/FLK pin strip.

Number of connections :-  1.

Number of positions  :- 40.

Supported Controller.

Controller :-

ALLEN-BRADLEY SLC 500suitable I/O card :-   1746 OB 32.

1746 OV 32.1746 IB 32.1746 IV 32.

Standard and Regulations.

Standards/regulations :-  IEC 60664.

Rated insulation voltage  :-   63 V.

Rated surge voltage :-      0.6 kV.

Insulation  :-     Functional insulation.

Degree of pollution :- 2O.

overvoltage category :- II.
