IC697BEM741 – GE Fanuc
In-Stock: 1
Available, can ship immediately
Part Details:
GE Phase Logic Interface Board.
Model :- DS200PLIBG2ACA.
Series :- Mark V.16.000 MHz.
This system was designed to control steam or gas turbines.
The PLIB board is typically used in conjunction with EX2000 digital regulator systems, which are used with brushless excitation systems.
These systems control the AC terminal voltage or the reactive volt-amps via control of the brushless exciter field.
Control can be either three-phase or single phase.
Within a triple modular redundant turbine control panel, each servo valve will have three coils with one coil from each servo connected to the R/S/T phases.
It has multiple vertical pin connectors that are located along the center and bottom edge of the board.
The board is also populated with multiple resistor network arrays, integrated circuits, LED indicators, as well as capacitors, resistors, and diodes.
