IC697MDL65324 – GE Fanuc
In-Stock: 1
Available, can ship immediately
Part Details:
Discrete Input Module.
Model/Part No : IC697MDL653.
24 Volt DC Positive/Negative Logic, 32-Point Input Module.
Rated Voltage : 24 volts DC.
Inputs per Module : 32 (four groups of eight inputs each).
Isolation : 1500 volts - any input to backplane , 500 volts between input groups.
Input Voltage Range (Vs) : -3 to +30 volts DC.
Input Current : 10mA (typical) at rated voltage.
Input Impedance : 2.6K ohm, typical On-state.
Voltage : 13.5 volts to 30 volts.
On-state Current : 6mA to 15mA.
Off-state Voltage : 0 volts to 5 volts.
Off-state Current : 0 to 2mA (2mA minimum at 5V input).
Filter Delay Time : 1mS or 10mS configurable.
Current Required from 5V Bus : 0.30 amp.
Discrete Input Module : System designed to support the VME standard C.1.
