IC697PWR710J – GE Fanuc
In-Stock: 1
Available, can ship immediately
Part Details:
Power Supply Module.
Model : IC697PWR710J.
Nominal Rated Voltage : 120/240VAC, 125VDC.
Input Voltage range : AC : 90 to 264 VAC, 47 to 63 Hz.
DC : 100 to 150 VDC.
Input Power : 90 watts maximum at full load.
Input Half Cycle Peak Inrush : 3 amps (typical).
Power Factor : > .95.
Output Power : 56 watts maximum.
Output Voltage : +5 .
VDC : 4.90 to 5.25 volts (5.1 volts nominal).
Protective Limits -Overvoltage Limit : 6.2 volts (typical), electronic over voltage protection.
Overcurrent Limit : 12 amps (typical), electronic current limit.
Ride Through Time : 21 milliseconds minimum (from loss of AC input).
VME : System designed to support the VME standard C.1.
