IC697PWR713G – GE Fanuc

Power Supply Module. from GE Fanuc

Product Specifications

Model/Part Number: IC697PWR713G

Warranty: One year

Part Type: Power Supply Module.

Delivery: 1 week

Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.

In-Stock: 1

Available, can ship immediately

Part Condition

Choose Part Conditions

Part Availability

Choose Part Availability

Part Details:

Power Supply Module.

Model : IC697PWR713G.

Nominal Rated Voltage : 120 VAC or 240 VAC.

Input Voltage Range : 90-132 V or 180-264 V, 47-63 Hz.

Input Power : 160 watts maximum at full load.

Input Half Cycle Peak Inrush : 55 amp (typical), 77 amp (maximum).

Output Power : 100 watts maximum (total for all 3 outputs) Output.

Voltage : +5 VDC: 4.90 to 5.25 volts (5.07 volts nominal).

+12 VDC : 11.75 to 12.6 volts.-12.

VDC : -12.6 to -11.75 volts.

Protective Limits -Overvoltage Limit : +5 VDC.

Output : 5.7 to 6.7 volts.

Overcurrent Limit : +5 VDC.

output : 26 amp, maximum+12 VDC.

output : 4 amp, maximum -12 VDC.

output : 2 amp, maximum.

Holdup Time : 21 ms.

minimum (from loss of AC input)VME : System designed to support the VME standard C.1.
