RD-WMB-T – Trend
Digital Output Module from Trend
Product Specifications
Model/Part Number: RD-WMB-T
Industrial Usage: Programmable Logic Controller (PLC)
Warranty: One year
Part Type: Digital Output Module
Brand/Manufacturer: Trend
Origin: UK (Assembled in Mexico)
Delivery: 1
Note: Proconex Pvt. Ltd. is NOT an authorized distributor for any of the brands mentioned on this website.
In-Stock: 1
Available, can ship immediately
Part Details:
Trend Wallbus Room Display Unit.
Descriptions:
The RD-WMB is part of the Wallbus room module family, pictured left, which has been designed to satisfy requirements at all stages of the contractual chain. The family has features that will appeal to architects, consultants, installation engineers, commissioning engineers, facility managers and building occupants. All units in the Wallbus family are fully interchangeable allowing room/space specifications to be changed by simply changing the front plate. The RD-WMB allows occupants to adjust fan speed, setpoint (graphical or numerical)and occupancy status and also to read associated values on a backlit, monochrome, LCD display.
Mounting place : Internal wall.
Temperature Range : 0 to 50C.R.H.
range : 0 to 90%rh.
Percentage of full current : 12.8.
Maximum No. on wallbus : 7.
Protection class : IP30.
