CDT-2N40-LCD – DWYER
In-Stock: 1
Available, can ship immediately
Part Details:
CARBON DIOXIDE/TEMPERATURE TRANSMITTER.
Model No : CDT-2N40-LCD.
Sensor : Single beam, dual wavelength NDIR.
Temperature : 32 to 122°F (0 to 50°C).
Temperature Dependence : ±8 ppm/°C at 1100 ppm.
Non-Linearity : 16 ppm.
Pressure Dependence : 0.13% of reading per mm of Hg.
Response Time : 2 min for 99% step change.
Duct Air Velocity Range : 0-4000 FPM (20.32 m/s).
Temperature Limits : 32 to 122°F (0 to 50°C).
Power Requirements : 16 to 35 VDC or 19 to 28 VAC.
Power Consumption : Average: 2 w; Peak: 3.75 w.
Output :
Current : 4 to 20 mA (max. 500 Ω).
Voltage : 0 to 5 VDC or 0 to 10 VDC (min. 500 Ω).
Relay : SPST NO rated 2 A @ 30 VDC.
Agency Approvals : CE.
