RHP-5D1E – DWYER
In-Stock: 1
Available, can ship immediately
Part Details:
TEMPERATURE/HUMIDITY TRANSMITTER.
Model no : RHP-5D1E.
Part No : RHP S94691815.
Relative Humidity range : 0 to 100 % RH.
Temperature Range : -40 to 140deg F(-40 to 60 deg C).
Hysteresis : ±1%.
Repeatability : ±0.1% typical.
Storage Temperature : -40 to 176deg F(-40 to 80Deg C).
Compensated Temperature Range : -4 to 140DegF(-20 to 60 deg C).
4-20mA Loop Powered Models :
Power Requirements : 10-35 VDC.
Output Signals : 4-20 mA, 2 Channels for humidity/solid state. temperature, sensor models(loop powered on RH).
RH sensor : Capacitance polymer.
