RHP-3D22 – DWYER
In-Stock: 1
Available, can ship immediately
Part Details:
Humidity/Temperature Transmitter.
Model No : RHP-3D22.
RHP-3D22 : Humidity/Temperature Transmitter, 3%, Duct Mount with Membrane Filter, 0-10V RH and Temperature Output.
POWER : 15-35 VDC, 15-29 VAC.
Product Series : Dwyer RHP Series Humidity/Temperature Transmitter.
Temperature Type : Humidity/Temperature Sensors.
Sensor Type : Duct Sensor.
Accuracy : 3%.
Relative Humidity Range : 0 to 100%.
Accuracy (Temp) : +/-0.2°C at 25°C.
Output(s) : 0 - 10 V (RH); 0 - 10 V (Temperature).
Voltage : 15 - 35 VDC or 15 - 29 VAC Max.
Temperature : -40 to 140.
Construction : PBT Housing
Standards/Approvals : CE Approved
