RHP-3D1F – DWYER

Part Details:

Humidity/Temperature Transmitter.

Model No : RHP-3D1F.

POWER SUPPLY : 10-35 VDC.

RHP-3D1F - Humidity/Temperature Transmitter, 3%, Duct Mount With Membrane Filter, 4-20mA RH and 20K Ohm Thermistor Temperature Output.

Sensor Type : Duct Sensor.

Temperature Type :  Humidity/Temperature Sensors.

Accuracy :  3%.

Relative Humidity Range : 0 - 100%.

Humidity/Temperature Transmitter : +/-0.2°C at 25°C.

Connection  :

Electrical Connection : Removable Screw Terminal Block.

Conduit Connection : 1/2" NPS.

Output(s)  :  4-20mA (RH), 20K Ohm at 25°C Thermistor (Temperature).

Voltage :  10-35 VDC.

Max Temperature :  -40 to 140°F.

Construction :  PBT.

Mounting Options :  Duct Mount With Membrane Filter.

Housing Type : RHP Series Duct Mount w/Membrane Filter.

Standards/Approvals :  CE Approved.
